SL-2540 1.2KV Polycarbonate Electrical Low Voltage Insulator
•Item number: SL-2540
•Dimension: 45X25X40mm
•Rate Voltage: 1.2KV
•Working Temperature: 1800C
•Insulator Material: Thermoplastic
•Color: Black
•Default Screw: M8
•Rated Torque(N-m): 6
•Packing: 300pcs/1ctn / N.W. :8.0kgs /carton
| Series Name |
ET-12 |
SL-2540 |
SL-3550 |
SL-4050F |
SL-3035 |
SL-3040 |
| Picture |
 |
 |
 |
 |
 |
 |
|
Dimensions
L*W*H [mm]
|
142*36*70 mm |
45*25*40 mm |
64*36*50 mm |
66*40*49 mm |
30*32*35 mm |
30(40)*40 mm |
|
Rated Voltage [V]
|
11 KV |
1.2 KV |
1.2 KV |
1.2 KV |
6.6 KV |
6.6 KV |
| Working Temp. |
+1000C |
+1100C |
+1100C |
+1100C |
+1100C |
+1100C |
|
Insulator Material
|
Resin |
Thermoplastic |
Thermoplastic |
Thermoplastic |
Epoxy |
Epoxy |
| Color |
Black |
Black |
Black |
Black |
Red |
Red |
| Default Screw |
M10 |
M8 |
M10 |
M10 |
M8 |
M8 |
Alternative Screw
(MOQ required) |
N/A |
M6,
1/4", 5/16" |
M8, M12,
5/16", 3/8", 1/2" |
M8, M12,
5/16", 3/8", 1/2" |
N/A |
N/A |
| Rated Torque [N-m] |
10 |
6 |
10 |
10 |
6 |
6 |
| Drawing |
ET-12 Drawing |
|
|
|
|
|
|
|
|
|
|
|
|
|
